INSTMED  ·  Medical Technology from Armenia

Making long-term ECG monitoring more accessible.

INSTMED develops portable Holter ECG systems and software for long-term ECG recording and medical evaluation.

INSTMED Holter Model-A device with 12-lead, 10-wire cable set

Medical Technology from Armenia

INSTMED is an Armenian medical technology company developing medical devices and software solutions for long-term ECG monitoring.

Our focus is to make Holter examinations more accessible by combining locally developed hardware, software and technical support.

INSTMED Holter Model-A

Portable 12-lead Holter ECG system for long-term recording.

INSTMED Holter Model-A device with 12-lead, 10-wire cable set
  • ECG channels
    12-lead ECG
  • Leads
    10 wires
  • Recording time
    48+ hours continuous recording
  • Analog front end
    24-bit ADC — ADS1298
  • Sampling rate
    500 Hz
  • Data storage
    MicroSD
  • Software
    PC software for ECG visualization and analysis
  • Dimensions
    61 × 56.5 × 17.5 mm
  • Weight, with battery
    65 g
  • Weight, without battery
    41 g
  • More than a device

    Device

    Portable 12-lead Holter ECG monitor for long-term recording.

    Software

    PC software for ECG visualization, signal processing and analysis.

    Analysis support

    ECG signal processing, rhythm and event detection, noise evaluation and AI/ML-assisted ECG classification tools that help physicians find and evaluate relevant ECG segments.

    Technical support

    Local technical support for medical centers using INSTMED Holter systems.

    INSTMED aims to provide medical centers with an integrated Holter examination solution rather than simply supplying hardware.

    Official Status

    INSTMED Holter Model-A has completed official technical approval, testing and device verification procedures in Armenia.

    Type Approval

    Type approval confirmed in Armenia for INSTMED Holter Model-A.

    Device Validation

    Certificate of Pattern Approval of Measuring Instruments issued for INSTMED Holter Model-A.

    Technical Testing

    EMI and electrical safety testing completed through ArmCert.

    Device Verification

    5 INSTMED Holter devices officially verified and calibrated.

    Holter services for medical centers

    INSTMED is developing a service model for hospitals, polyclinics, cardiologists and other medical centers performing Holter examinations.

    Medical centers can use INSTMED Holter devices together with the PC software and local technical support. The long-term goal is to make Holter examinations more accessible and affordable, including outside Yerevan.

    Making Holter monitoring more accessible

    INSTMED aims to improve access to long-term ECG monitoring by reducing technological and cost barriers and expanding availability beyond Yerevan.

    Access

    More medical centers able to provide Holter examinations

    Patients

    More patients receiving long-term ECG monitoring

    Reach

    Expansion of Holter services outside Yerevan

    Value

    More accessible examination costs

    Impact indicators will be measured as real-world use of the service begins.

    The next generation of INSTMED Holter

    Holter Model-A BLE connectivity Home monitoring Cloud platform AI-assisted ECG analysis Remote medical evaluation

    The next development stage will connect the Holter system to smartphones and cloud infrastructure, enabling home monitoring, remote data transfer and expanded AI-assisted ECG analysis.

    These are planned developments and are not all current capabilities of Holter Model-A.

    From Armenia to international markets

    INSTMED plans to prepare the product for European market entry by completing the required conformity and certification processes.

    Current

    Armenian type approval, technical testing and official device verification

    Next

    European conformity and certification process

    Future

    International market entry and scalable Holter services

    The European conformity and certification process is planned to be carried out through TÜV's Armenian branch.

    Founder

    Hakob Hakobyan

    Founder, INSTMED

    Founder of INSTMED with practical experience in cardiology, arrhythmology and medical equipment, combined with engineering and research experience in cardiac devices and safety-critical systems.

    Hakob Hakobyan previously conducted research at Politecnico di Torino on pacemakers, hardware virtual models and safety-critical system testing.

    Contact INSTMED

    Company
    INSTMED LLC
    Armenia
    Founder
    Hakob Hakobyan
    Website
    instmed.am
